Oupiin
Oupiin is considered one of the most modern connector manufacturers in the world. Altronics have been supplying Oupiin product to Australian manufacturers and enthusiasts since the 1980's and they have proven to provide a consistent, quality product. We even use many of their connector products in our own manufactured items.
8 Way 3.96mm 90 Deg. Header
P5628
8 Way. PCB Mount. 90 Deg. Pin Header. 3.96mm Spacing. Rated at 7A. Includes Crimp Pins.
8 Way 3.96mm 90 Deg. Header (10 Pack)
P5628
8 Way. PCB Mount. 90 Deg. Pin Header. 3.96mm Spacing. Rated at 7A. Includes Crimp Pins.
8 Way 3.96mm PCB Mount Pin Header
P5608
8 Way. PCB Mount. Straight Pin Header. 3.96mm Spacing. Rated at 7A. Includes Crimp Pins.
8 Way 3.96mm PCB Mount Pin Header (10 Pack)
P5608
8 Way. PCB Mount. Straight Pin Header. 3.96mm Spacing. Rated at 7A. Includes Crimp Pins.
84 Pin Surface Mount PLCC Socket
P5598
Contact Resistance: 30M Ohm Max @ DC 100mA Insulation Resistance: 1000M Ohm Min @ DC 250V Current Rating: 1 Amp Dielectric Voltage: AC 500V for 1 Minute Operating Temp: -55° to 105° C Tin Plated Contacts
84 Pin Surface Mount PLCC Socket (16 Pack)
P5598
Contact Resistance: 30M Ohm Max @ DC 100mA Insulation Resistance: 1000M Ohm Min @ DC 250V Current Rating: 1 Amp Dielectric Voltage: AC 500V for 1 Minute Operating Temp: -55° to 105° C Tin Plated Contacts
8P8C RJ45 Modular Socket Low Profile Enclosed PCB Mount
P1438
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Low Profile PCB Mount
P1428
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Low Profile PCB Mount
P1448
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Low Profile PCB Mount
P1448A
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Low Profile PCB Mount Red
P1429
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Shielded PCB Mount
P1538
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Surface Mount
P1478
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 Modular Socket Top Entry PCB Mount
P1468
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
8P8C RJ45 PCB Mount Modular Socket 4-Way
P1483
Housing: Thermoplastic Polyester Glass Filled UL94V-0 Contact: Copper Alloy Insulation Resistance: 1000MΩ Minimum Contact Resistance: 30MΩ Max. per contact Current Rating: 1.5 Amps
8P8C RJ45 PCB Mount Modular Socket 4-Way
P1483A
Housing: Thermoplastic Polyester Glass Filled UL94V-0 Contact: Copper Alloy Insulation Resistance: 1000MO Minimum Contact Resistance: 30MO Max. per contact Current Rating: 1.5 Amps
96 Pin Female Rows A-B&C PCB Mount DIN 41612
P4996
Moulded glass-filled polyester connectors to DIN 41612 with gold contacts. The plug moulding houses single piece 90 deg. Angled pins on a 0.1 inch pitch between rows, allowing horizontal mounting on Eurocards whilst the mating sockets have flow solde
96 Pin Male Rows A-B&C 90 Deg. PCB Mount DIN 41612
P4896
Moulded glass-filled polyester connectors to DIN 41612 with gold contacts. The plug moulding houses single piece 90 deg. Angled pins on a 0.1 inch pitch between rows, allowing horizontal mounting on Eurocards whilst the mating sockets have flow solde
