Oupiin
Oupiin is considered one of the most modern connector manufacturers in the world. Altronics have been supplying Oupiin product to Australian manufacturers and enthusiasts since the 1980's and they have proven to provide a consistent, quality product. We even use many of their connector products in our own manufactured items.
40 Way x 2 Header Pin Strip
P5410
Single and dual row models available in straight or 90 pin types. Both have 2.54mm pin spacing. Gold Plated Contacts
40 Way x 2 Header Pin Strip (10 Pack)
P5410
Single and dual row models available in straight or 90 pin types. Both have 2.54mm pin spacing. Gold Plated Contacts
40 Way x 2 SMD Header Pin Strip
P5415
Dual row model available with SMD pins. Both have 2.54mm pin spacing. Gold Plated Contacts
40 Way x 2 SMD Header Pin Strip (10 Pack)
P5415
Dual row model available with SMD pins. Both have 2.54mm pin spacing. Gold Plated Contacts
40 Way x 3 Header Pin Strip
P5446
3 row PCB header strip with standard 2.54mm spacing, gold plated contacts and 40 pins per row.
40 Way x 3 Header Pin Strip (10 Pack)
P5446
3 row PCB header strip with standard 2.54mm spacing, gold plated contacts and 40 pins per row.
4P4C RJ10 Modular Socket Low Profile Enclosed PCB Mount
P1432
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
4P4C RJ10 Modular Socket Low Profile PCB Mount
P1422
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
4P4C RJ10 Modular Socket Low Profile PCB Mount
P1442
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
4P4C RJ10 Modular Socket Low Profile PCB Mount
P1442A
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
4P4C RJ10 Modular Socket Surface Mount
P1472
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
4P4C RJ10 Modular Socket Top Entry PCB Mount
P1462
Housing: PBT Mixed 15% Glass Fibre, 94V-O Contact: Gold Plated Phosphor Bronze Alloy Insulation Resistance: 10M Ohm Minimum Contact Resistance: 20M Ohm Max. per contact Dielectric Withstand Voltage: 1000V AC RMS 60Hz Current Rating: 1.5 Amps Mechanical Life: 500 cycles minimum Retention Strength: 7.7kg between plug & socket
