DC-DC Converter Module 3.8-32V In / 1.25-35V Out

Be the first to review this product
A converter module allowing a low input voltage to be increased to a higher output voltage. Input 3.8-32V DC. Output 1.25-35V DC. Ideal for powering higher voltage devices from a typical 5V microcontroller platform. 3A continuous current.
SKU: Z6338X
$4.55
Per ea
QuantityPrice
ea$4.55

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

A converter module allowing a low input voltage to be increased to a higher output voltage. Input 3.8-32V DC. Output 1.25-35V DC. Ideal for powering higher voltage devices from a typical 5V microcontroller platform. 3A continuous current.

Please make sure the output voltage is set higher than the input voltage. Otherwise the module will be damaged. ALWAYS check the output voltage with a multimeter prior to connecting your device to the output.

Specifications

Input Range: 3.8V to 32V.

  • Output Range: 1.25V to 35V.
  • Input Current: 3A (max),
  • No-Load Current: 18mA (5V input, 8V output*)
  • *No-load current is less than 18mA. Higher the voltage, the greater the no load current.

12 Months

We Offer 12 Months for this product
