Microchip ATSAMD21G17 Microcontroller 48 Pin TQFP

SKU: Y1860
A low-power, high-performance Microchip's ARM® Cortex®-M0+ based flash microcontroller, the ATSAMD21G17 is ideal for a wide range of home automation, consumer, metering, and industrial applications. As used in the Arduino Zero.
$9.32

All Prices Shown are (ex GST)
Bulk Pricing
ea $9.32
4+ $8.68
10+ $8.00
i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview

A low-power, high-performance Microchip''s ARM® Cortex®-M0+ based flash microcontroller, the ATSAMD21G17 is ideal for a wide range of home automation, consumer, metering, and industrial applications. As used in the Arduino Zero.

Features

  • 128KB of flash and 16KB of SRAM
  • Up to 48MHz operating frequency
  • Six serial communication modules (SERCOM) configurable as UART/USART, SPI or I2C, three 16-bit timer/counters, 32-bit Real-Time Clock and calendar, 20 PWM channels, one 14-channel 12-bit ADC, one 10-bit DAC
  • Full Speed USB 2.0 Device and embedded Host
  • Support for up to 120 touch channels
  • 1.62V to 3.63V power supply
  • Easy pin migration to SAMD21G and SAMD21J devices
  • Supported by Atmel Studio, ASF and the SAM D21 Xplained Pro kit
  • 38 GPIOs
  • Operates between-40ºC and 85ºC

Specifications

Family SAM D21

  • Max Speed MHz 48
  • Program Memory Size (KB) 128
  • RAM (KB) 16
  • Auxiliary Flash (KB) 0.064
  • Temperature Range (C) -40 to 85
  • Operating Voltage Range (V) 1.62 to 3.63
  • DMA Channels 12
  • SPITM 6
  • I2CTM Compatible 6
  • Peripheral Pin Select (PPS) Crossbar Yes
  • USB 1
  • USB Interface Host, Device
  • A/D channels 14
  • Max A/D Resolution 12
  • Max A/D Sample Rate (KSPS) 350
  • Input Capture 6
  • Motor Control PWM Channels 6
  • 16-bit Digital Timers 5
  • Parallel Port GPIO
  • Comparators 2
  • Internal Oscillator 32khz, 32Khz ULP, 8Mhz
  • RTCC Yes
  • I/O Pins 38
  • Pin Count 48
