17AWG Heavy Duty Automotive Black Figure 8 Cable (100 Roll)

Be the first to review this product
Double PVC insulated twin. Separate conductors with non-bonded sheath.
SKU: W4146
$2.05
Per m
QuantityPrice
m$2.05
100+$1.55

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Double PVC insulated twin. Separate conductors with non-bonded sheath.
Roll Size: 100m

Cross Section

Specifications:

Size: 2 x 14/0/30

  • Voltage Rating: 300V AC
  • Current Rating: 10A
  • Outside Dimensions: 3.8 x 6.2mm
  • Conductor Area: 1.0mm2
  • Conductor Gauge: 17AWG
  • Temperature Rating: 75°C

12 Months

We Offer 12 Months for this product
