Shielded Audio/Data Cable

Be the first to review this product
Aluminium mylar shield with drain wire. Conductor colours: Black & White
SKU: W3036
$1.45

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

This date cable has a aluminium mylar shield with drain wire.

Cross Section

Specifications

Conductor colours: Blue & White

  • Conductor
  • Gauge: 24AWG
  • Material: Tinned copper
  • Construction: 7/0.20 +/-0.008mm
  • Insulation
  • Standard thickness: 0.29mm
  • Minimum thickness: 0.25mm
  • Diameter: 1.20 +/-0.05mm
  • Material: Poly vinyl chloride
  • Colour: White/Blue
  • Drain Wire
  • Material: Tinned copper
  • Construction: 7/0.20 +/-0.008mm
  • Strand
  • Construction: 24AWG + mylar + drain wire + aluminium foil
  • Jacket
  • Reference thickness: 1.0mm
  • Diameter: 5.0 +/-0.05mm
  • Material: Poly vinyl chloride
  • Colour: Gray
  • Conductor Area: 0.22mm2 (24AWG)
  • Temperature Rating: 60ºC
  • Roll Size: 100m
