4 Megapixel Fish Eye Lens Wi-Fi IP Dome Camera

SKU: S9109
This "FISH EYE" lens camera is ideal for open plan office installations this camera allows you to record everything with a 360° panoramic view. The fish eye footage is then viewed via NVR/mobile app/VMS. This can reduce the number of cameras required to cover the same area with standard cameras. It captures a maximum of 2160x2160 @ 15fps.
$226.36

All Prices Shown are (ex GST)
Bulk Pricing
ea $226.36
2+ $208.18
4+ $180.91
i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview

This ‘fish eye’ lens camera is ideal for open plan office installations this camera allows you to record everything with a 360° panoramic view. The fish eye footage is then viewed via NVR/mobile app/VMS. This can reduce the number of cameras required to cover the same area with standard cameras. It captures a maximum of 2160x2160 @ 15fps. Higher frame rate is available at lower resolutions.


Android App - Link to Google Play Store

Apple iOS App - Link to iTunes Store

Features:

  • H.264, H.265, JPEG compression
  • 4 megapixel
  • 2 way audio
  • Micro SD card slot
  • Alarm input
  • Simultaneous multiple streams
  • Supports ONVIF
  • Internal PoE receiver
  • 802.11b/g/n Wi-Fi on board
  • Motion detect triggering

Specifications:

Camera

  • Image Sensor: 1/2.9" SONY Low Illumination CMOS Sensor
  • Resolution: 4MP
  • Effective Pixels: 3096 (H) × 2202 (V)
  • Compression: H.264/H.265/JPEG/AVI/MJPEG
  • TV System: PAL/NTSC
  • Electronic Shutter Time: Auto= PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec
  • S/N Ratio: ≥52dB
  • Scanning System: Progressive
  • Video Output: Network, cvbs
  • Reset Button: YES

LENS Type

  • Focus Length: Board Lens 1.05mm
  • Focus Control: Fixed
  • Lens Type: Fixed
  • Pixels: 5MP

Night Vision

  • Infrared LED: 42µx 3PCS
  • Infrared Distance: 20M
  • IR Status: Under 10 Lux By CDS
  • IR Power On: CDS Auto Control

Network

  • Ethernet: RJ-45 (10/100Base-T)
  • Protocol:TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP, RTCP,NTP,SMTP
  • ONVIF: Support ONVIF 2.4
  • P2P: YES, Support QR Code
  • POE: Internal POE, Support IEEE 802.3af
  • Video Delay: 0.3S (Within the Lan)
  • Main Stream: 12048*2048@15fps
  • Main Stream: 21520*1520@20fps
  • Main Stream: 31024*1024@20fps
  • Sub Stream: 1720*720@15fps | 720*720@20fps
  • Tri Stream: 512*512@15fps | 512*512@20fps
  • IE Brower: IE8-11, Google Chrome, Firefox, Safari, Mac Safari
  • Smart Phone: iPhone, iPad, Android, Android Pad

Wireless

  • Antena: 3dbi
  • Wi-Fi: Wi-Fi(IEEE802.11b/g/n)
  • WIFI Range: No obstacles 300m Max.

Interface

  • Audio: 2-way audio(3.5mm audio interface)
  • Alarm: 1channel Input/Ouput
  • SD Card Slot: support 64G Micro SD

General

  • Housing: Body:Metal, Bracket: Plastic
  • Anti-cut Bracket: NO
  • IR Cut Filter: YES
  • Operation Temperature: -20℃ ~ +60℃ RH95% Max
  • Storage Temperature: -20℃ ~ +60℃ RH95% Max
  • Power Source: DC12V±10%, 950mA
  • Dimension: ￠120 x 49(H) mm
  • Weight: 500g

Warranty & Returns

12 Months

We Offer 12 Months for this product

Specifications

Products specifications
Warranty Group
Warranty 12 Months
