7.5A 24VDC SPST PCB Mount Relay

SKU: S4252B
Non-Sealed type, suitable for flow soldering.
$3.05

All Prices Shown are (ex GST)
Bulk Pricing
ea $3.05
10+ $2.73
40+ $2.41
i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview

Non-Sealed type, suitable for flow soldering.

Specifications:

Max switching voltage: 277V AC, 30V DC

  • Max switching current: 10A
  • Max VA (Watts): 1250VA (150W)
  • Contact material: Silver Alloy
  • Coil resistance: 1280Ω
  • Max coil power: 200mw
  • Insulation resistance: >100MΩ @ 500V DC
  • Dielectric strength (for 1 min):
  • 1000V AC between open contacts
  • 2500V AC between coil & contact
  • Electrical life: 100,000 operations
  • Mechanical life: 10 million operations
  • Dimensions: 10W x 19L x 15H mm

Warranty & Returns

12 Months

We Offer 12 Months for this product

Specifications

Products specifications
Warranty Group
Warranty 12 Months
