6A 240V AC/DC Input SPDT DIN Rail Cradle Relay

Be the first to review this product
A super slimline DIN rail mount relay designed for industrial switching applications. Suits standard 35mm DIN rail. Supplied with 60V DC coil relay.
SKU: S4166
$20.45
Per ea
QuantityPrice
ea$20.45
10+$18.41
30+$16.36

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

A super slimline DIN rail mount relay designed for industrial switching applications. Suits standard 35mm DIN rail.  Supplied with 60V DC coil relay.

Specifications

Nominal voltage: 250V AC

  • Nominal current: 6A
  • Cradle input voltage: 220-240V AC/DC
  • Nominal coil voltage: 60V DC
  • Pick-up voltage (max): 45V DC
  • Drop-out voltage (min): 3.0V DC
  • Max voltage: 90V DC
  • Coil resistance: 16,600Ω. (+/- 15%)
  • Max switching power AC: 1500VA
  • Max switching power DC: 180W
  • Contact material: Silver alloy
  • Max coil power: 210mW
  • Insulation resistance: >1000MΩ @ 500V DC
  • Dielectric strength (for 1 min):
  • 1000V AC between open contacts
  • 4000V AC between coil & contact
  • Life: 60,000 electrical, 10 million mechanical
