SP3T Solder Tail Mini Toggle Switch

Manufacturer: Salecom
Be the first to review this product
The Salecom range of miniature and sub-miniature switches are pin for pin compatible with several other leading brands but at a fraction of the cost.
SKU: S1380
$7.23
Per ea
QuantityPrice
ea$7.23
10+$6.50
40+$5.77

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

The Salecom range of miniature and sub-miniature switches are pin for pin compatible with several other leading brands but at a fraction of the cost. Already many major manufacturers across Australia use the Salecom brand in preference to the more expensive makes. Salecom offers excellent value for money. Typically Salecom switches are reliable for up to 50,000 switching operations at full ratings.

Note: Includes an actuator that cannot be operated accidentally. To switch on or off the actuator must be pulled out before switching can take place.


Pack Includes:
1 x star washer
1 x flat locking washer
2 x nuts


Dimensions:


Switching Schematic:

Specifications

Contact Resistance: 10mO max

  • Insulation Resistance: 1,000M Ω min
  • Dielectric Strength: 1500V a.c. 50/60Hz
  • Soldering Temperature: 260°C
  • Duration of Solder Immersion: 5 ± 1
  • Resistance Low Temperature: -30 ± 3°C
  • Resistance High Temperature: 85 ± 3°C
  • Resistance Humidity Temperature: 40 ± 2°C
  • Relative Humidity: 90-95%

12 Months

We Offer 12 Months for this product
