0.39uF 16V Y5V 0805 SMD Chip Capacitor Reel 3K

SMD Chip Capacitor.
Reel of 3000.


SMD Resistor Value Markings:
0603 series
Our range of 0603 resistors use a combination of normal 3 digit marking and the EIA-96 marking system. The normal 3 digit marking is identified by 3 digits, the first 2 digits are the value followed by the multiplier, or number of zeros. ie. 333 printed on the resistor equates to 33 + three zeros = 33,000 Ohm or 33K Ohm (1% markings are the same as 5% markings). The EIA-96 marking used for selected values is as per the table above.

0805 & 1206 series
Identified by a 4 digit figure, the first 3 digits are the value followed by the multiplier, or number of zeros. ie. 1503 printed on the resistor equates to 150 + three zeros = 150,000 Ohm or 150K Ohm




Package Size (cm)



PCB Pad Layout (cm)
