2-7pf Red Trimmer Capacitor (10 Pack)

Be the first to review this product
D Series, top adjust, 2 pin, Colour coded for range identification.
SKU: R4001
$1.82
Per ea
QuantityPrice
ea$1.82
10+$1.73
25+$1.32

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

D Series.
Top adjust.
Red. 2 pin. 2-7pF.
Colour coded for range identification.


Specifications

Pitch: 5.8mm

  • Working Voltage: 250V DC
  • Withstand Voltage: 550V DC
  • Insulation Resistance: 10G Ohm min at 250V DC
  • Operating Temperature: -55°C to +85°C
  • Q Value: >1000 at 1MHz at max setting

12 Months

We Offer 12 Months for this product
