0.47uF 630V 26mm Greencap Capacitor

SKU: R2784C
Non-inductive, High temperature stability, Ideal for coupling & bypass applications Specifications Tolerance: ±5% Pitch: 20.5mm Voltage: 630V DC Temperature Rating: -40C to +85°C
$2.05

All Prices Shown are (ex GST)
Bulk Pricing
ea $2.05
10+ $1.41
100+ $1.18
i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview

Mylar Polyester
Non-Inductive
High Temperature Stability
Ideal for coupling and bypass applications

Note: All quantities are supplied loose.

Features

  • Inductive welded construction
  • Epoxy dip coated for superior heat, humidity and solvent resistance.
  • Good reputation in use with consumer & industrial electronics.
  • Optimum for automatic insertion due to their small size and light weight.

Specifications

Operating Temperature: -40C~ +85C

  • Rated Voltage: 100V, 250V, 400V, 630V, 1000V.DC
  • Capacitance Range: 0.001 ~ 0.47microF
  • Capacitance Tolerance: +/-5%, 10%, 20%
  • Insulation Resistance: 0.1microF >=30,000Mohm min, >0.1microF >15000Mohm
  • Dissipation Factor: <=0.1 (at 1KHz)
  • Dielectric Strength: 200% of rated voltage for 5 sec.

Warranty & Returns

12 Months

We Offer 12 Months for this product

Specifications

Products specifications
Warranty Group
Warranty 12 Months
