0.068uF 100V 6.5mm Greencap Capacitor (100 Pack)

Be the first to review this product
Inductive welded construction epoxy dip coated. Optimum for automatic insertion due to their small size and light weight. Coated with epoxy resin for superior heat resistance, humidity resistance and solvent resistance.
SKU: R2732B
$0.32
Per ea
Quantity Price
ea $0.32
10+ $0.23
100+ $0.18

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Mylar Polyester
Non-Inductive
High Temperature Stability
Ideal for coupling and bypass applications

Note: All quantities are supplied loose.

Features

  • Inductive welded construction
  • Epoxy dip coated for superior heat, humidity and solvent resistance.
  • Good reputation in use with consumer & industrial electronics.
  • Optimum for automatic insertion due to their small size and light weight.

Specifications

Operating Temperature: -40C~ +85C

  • Rated Voltage: 100V, 250V, 400V, 630V, 1000V.DC
  • Capacitance Range: 0.001 ~ 0.47microF
  • Capacitance Tolerance: +/-5%, 10%, 20%
  • Insulation Resistance: 0.1microF >=30,000Mohm min, >0.1microF >15000Mohm
  • Dissipation Factor: <=0.1 (at 1KHz)
  • Dielectric Strength: 200% of rated voltage for 5 sec.

12 Months

We Offer 12 Months for this product
