20A 12V/24V DC PWM Solar Charge Controller

Be the first to review this product
A basic solar charge controller for permanent installations of lead acid or gel battery solar panel systems. It features a 3 stage charging sequence (boost, float and equalise). LEDs are provided to indicate working status - normal, fault, overload and low battery. Suitable for 12V or 24V systems, the charger automatically detects the connected b
SKU: N2012
$104.55
Per ea
QuantityPrice
ea$104.55
2+$95.45
4+$86.36

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

A basic solar charge controller for permanent installations of lead acid or gel battery solar panel systems. It features a 3 stage charging sequence (boost, float and equalise). LEDs are provided to indicate working status - normal, fault, overload and low battery. Suitable for 12V or 24V systems, the charger automatically detects the connected battery voltage. Ideally suited to simple remote power systems such as water pumping stations, electric fences, remote lighting, marine applications etc.

Features:

  • Suits lead acid or gel battery systems
  • Automatic fuse protection
  • Battery overload & deep discharge protection
  • Automatic 12/24V voltage selection
  • Reverse polarity protection
  • Short circuit protection
  • Status LEDs
  • Diode protection

Specifications:

No load PV current: 0mA

  • Standby current: 12V system: 23mA, 24V system: 11.5mA.
  • Max charge/load current: 20A
  • 12V low voltage dis/reconnect: 11.1V
  • 24V low voltage dis/reconnect: 23.4V
  • Max solar input voltage: 47V
  • Terminal wire size: 4AWG
  • Dimensions (mm): 177 x 96 x 43
