24V / 240V 5A EI Core Transformer

Manufacturer: Powertran
Be the first to review this product
Powertran EI-Core 240V AC mains transformer with 5A single tap secondary configuration.
SKU: M2190C
$63.59
Per ea
Quantity Price
ea $63.59
4+ $57.23
10+ $50.86

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Powertran EI-Core 240V AC mains transformer with 5A single tap secondary configuration. 24V secondary voltage available at 5A current output. Primary and secondaries fitted with 200mm flyleads. Fully electrical authority approved for AS/NZS 61558.2.6.

Note: Must be used with a standard 500mA external fuse. All currents listed are AC.



Specifications

Primary voltage: 240V AC

  • Total VA rating: 120VA
  • Insulation: Class E (120°C)
  • Magnetising current: <85mA
  • Temperature rise: <65°C
  • Regulation: Ëœ10%
  • Recommended primary AC fuse: 500mA
  • Weight: Ëœ1.4kg
  • Primary connection: 200mm fly leads
  • Secondary connection: 200mm fly leads

12 Months

We Offer 12 Months for this product
