PSG750 UPS 750VA Safeguard

Manufacturer: PowerShield
Be the first to review this product
The Office model is perfect for a home/office solution. It includes three battery backup and surge protected Australian sockets, three dedicated Australian outlets with surge protection and RJ45 phone line surge protection. Provides modified sinew
SKU: D0873
$171.82
Per ea
Quantity Price
ea $171.82

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

The Powershield SafeGuard 750VA Uninterruptible Power Supply (UPS) is designed for a home/office solution. It includes three battery backup and surge protected Australian sockets, three dedicated Australian outlets with surge protection and RJ45 phone line surge protection. Provides modified sinewave output and has an audible alarm when activated. Includes management software to suit most operating systems.


Visit the PowerShield UPS Sizing Guide. which will help you select the correct UPS for your power protection needs.

Features

  • Automatic Voltage Regulation (Buck and Boost)
  • Light-weight compact and elegantly designed
  • Intelligent microprocessor control
  • Monitoring and shutdown software included
  • Fax/modem/LAN surge suppression port
  • Overload protection and alarm
  • Output short circuit protection
  • Start on battery function (cold start)
  • USB communication
  • Easy user replaceable battery
  • Australian/New Zealand approved sockets
  • Wall mountable
  • Fast charging – 90% in 4 hours

Specifications

Capacity: 750VA / 450W Line interactive

Input:

  • Voltage: 240V a.c. (Nominal)
  • Voltage range: 177V a.c to 290V a.c.
  • Frequency: 50Hz or 60Hz (Auto Sensing)

Output:

  • Output voltage: 240V a.c. ±10%
  • Frequency Range (Batt. Mode): 50Hz or 60Hz ±-1Hz
  • Battery transfer time: 6 msec (typical)
  • Wave Form (Batt. Mode): Simulated Sine Wave
  • Australian Outlets: 3 (UPS and Surge Protection)
  • Australian Outlets: 3 (Full Time Surge Protection)

Battery:

  • Capacity: 12V/9Ah
  • Backup time: 25 min (1 PC load at 100W)
  • Typical Recharge Time: 6-8 hours recover to 90% capacity

Protection

  • Full Protection: Overcharge, discharge, short circuit and thermal protection
  • Surge Protection: 468Joules /11000Amps - Best in its class
  • Data Protection: Tel/modem/LAN, RJ45 connector

Communications and Management

  • Interface: USB interface
  • Software: PowerShield® NetGuard® supports Windows, Linux, Unix & Mac
  • LED Alarm: AC Mode, Battery Mode, Low Battery (Batt. Mode), Fault
  • Audible Alarm: Battery Mode, Low Battery (Batt. Mode), Fault

Physical

  • Dimensions: 292L x 91W x 199Hmm
  • Weight: 5.5kg

Operating Environment

  • Temperature: 0-400°C
  • Humidity: 0-90% (RH Non-condensing)
  • Noise Level: <5dB (No Fan)



2 Years

We Offer 2 Years for this product
