Dante Mic/Line 4 Input, 4 Output Dual Wallplate

Be the first to review this product
Dante Interface 4 x Mic/Line Inputs, 4 x Outputs
SKU: A4818
$1,017.27
Per ea
QuantityPrice
ea$1,017.27
2+$922.73
4+$831.82

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

This Dante Interface features 4 x Mic/Line Inputs and 4 x Outputs. Distributed audio signals over UTP cabling are becoming increasingly widespread in large building installations and multi-function venues. This product, used together with the rest in the range provide a connected solution for local zone inputs, feeding signals back to centrally located zone amplifiers. The system uses a proprietary standard called CSP which can be easily converted to the widely adopted Dante standard using the A 4830/A 4831 converter boxes. Powered by 24V DC input.

Features

  • Two Mic/Line XLR Inputs and one mini-jack input on Front Panel
  • Terminal Block for Two Audio Outputs on Rear Panel
  • One mini-jack output on front panel
  • Converts Mic or Line Audio Signals to Dante network
  • Mic or Line is Selectable for Each XLR Input
  • Switchable 48V Phantom Power for Each Mic XLR Input
  • Adjustable Mic/LIne Gain from -20 dB to +20dB for Each XLR input (Two Audio Signal Outputs from Dante Network)
  • Stereo/Mono switch for mini-jack input and output
  • Four audio signal outputs from Dante network
  • Balance or unbalanced signal outputs
  • Doesn''t require special software
  • High Resolution 24 Bit for DAC and ADC
  • Power over Ethernet (PoE) or 24VDC power supply
  • Provides High Quality of Preamplifier for microphones
  • Excellent Audio quality with low noise

12 Months

We Offer 12 Months for this product
