HDMI & One Way Infra-Red Cat6 Extender UTP Balun

Manufacturer: Dynalink
Be the first to review this product
Designed to extend HDMI signals over distances up to 60m across economical UTP cabling.
SKU: A3242
$235.45
Per ea
QuantityPrice
ea$235.45
2+$213.64
4+$190.00

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

This HDMI & One Way Infra-Red Cat6 Extender UTP Balun is designed to extend HDMI signals over distances up to 60m across economical UTP cabling. Maximum resolution of 4K @ 60Hz 4:4:4 is achieved when used with Cat6/6a/7 type cables. One way infra-red control of source equipment is also possible using the included infra-red target and emitter. Includes transmitter, receiver, IR target, IR emitter and power supply.

Features

  • Extends HDMI signals over distances up to 60m at 4k@ 60Hz 4:4:4 resolutions.
  • HDMI 2.0, HDCP 2.2 HDCP 1.4 and DVI 1.0 compliant
  • Supports 18Gbps bandwidth
  • Supports one HDMI loop output
  • Supports one-way IR pass-through
  • Supports HDR function

Specifications

HDMI Compliance: 2.0

  • HDCP Compliance: 2.2 / 1.4
  • Video Bandwidth: 18Gbps
  • Video Resolution: Up to 4K 60Hz 4:4:4
  • Max Distance Cat6/6a/7: 60M @ 4K 60Hz, 70m @ 4K 30Hz
  • Max Disrance Cat5e: 50M @ 4K 60Hz, 50M @ 4K 30Hz
  • Colour Space: RGB / YCbCr 4:4:4, 4:2:2, 4:2:0, YUB 4:4:4
  • HDMI Audio: LPCM 2.0/2.1/5.1/6.1/7.1, Dolby digital, True HD,
  • DD+, DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
  • Case Dimensions: 61W x 88D x 18Hmm
  • Power Supply: 12V DC 1A (included)

12 Months

We Offer 12 Months for this product
