HDMI & Infra-Red HDBaseT Cat5e/6 Extender UTP Balun

Manufacturer: Dynalink
Be the first to review this product
Utilises the latest HDBaseT technology to send full HD uncompressed HDMI signals over Cat 5e/6 cable.
SKU: A3215A
$317.27
Per ea
Quantity Price
ea $317.27
2+ $286.36
4+ $253.64

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Utilises the latest HDBaseT technology to send full HD uncompressed HDMI signals over Cat 5e/6 cable. Range up to 70m from source equipment. Infra-red control signals can also be relayed both ways, allowing you to control your equipment remotely. Compatible with Foxtel IQ.

Includes transmitter, receiver, IR target, IR emitter & power supply.

Features

  • 70m Range
  • HDBaseT single UTP
  • HDCP compliant
  • Transmitter or receiver unit can be powered via PoE
  • Supports uncompressed HDMI signal
  • Supports 1080p @ 60Hz (75m)
  • Supports 4K x 2K @ 60Hz 24bit (50m CAT5e) (60m CAT6)
  • Supports 3D passthrough
  • Supports LPCM, DTS digital, Dolby Digital, DTS-HD, Dolby True HD
  • Supports 3D
  • Supports HDbaseT technology
  • Bi-direction IR control (wide band, 20-60KHz)
  • Bi-direction delivery of power over cable
  • Supports EDID call back
  • Supports CEC pass through
  • Built-in ESD protection system

Specifications

Interface (Transmitters): HDMI Input, R2S232, HDbaseT OUT, DC 12V, IR IN, IR OUT

  • Interface (Receivers): HDMI Output, R2S232, HDbaseT IN, DC 12V, IR IN, IR OUT
  • Power Consumption: <16W (TX + RX with POC)
  • POE: 12V 2A DC adapter, any side of transmitter or receiver
  • Dimensions: 93 x 88 x 21mm
  • Video Bandwidth: Maximum TMDS clock frequency 600 MHz
  • Resolution and Distance: 3840*2160 at 60Hz (Ycbcr 4:4:4 24bit) (60m) Cat6
  • LED Status: Power LED Green; Video LED Yellow

12 Months

We Offer 12 Months for this product
