5.1CH Digital Audio Converter

Manufacturer: Dynalink
Be the first to review this product
This Audio decoder can auto convert optical/coaxial channel (Support LPCM/PCM/RAW) input to 2.0 channel analog audio output, and supports decoding Dolby AC-3/DTS (included 5.1 RAW digital audio streaming).
SKU: A3195A
$54.50
Per ea
QuantityPrice
ea$54.50
2+$49.05
4+$43.59

All Prices Shown are (ex GST)


i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

This Audio decoder can auto convert optical/coaxial channel (Support LPCM/PCM/RAW) input to 2.0 channel analog audio output, and supports decoding Dolby AC-3/DTS (included 5.1 RAW digital audio streaming). Compatible with the following network players; HDTV, Blu-ray DVD, Playstation, XBOX, DVD etc. It can be used to convert the digital output of a television into a standard stereo RCA for connection to amplifiers not fitted with digital audio inputs.

Dimensions: 81.7 x 78 x 21.2 mm

Included in Box
1x Decoder
1x Micro USB Power Cable
1x User Manual

Please Note: A USB power supply is required. We recommend our M8861C USB wall charger (see accessories below)

Features

  • Built-in high performance RTOS operating system and
  • audio decoder chip; supports DTS/AC-3
  • Super fast start time about 3 seconds
  • Auto Switch between optical and coaxial channel input
  • Auto decode AC-3/DTS (LPCM/PCM/RAW) input signal without any action
  • High compatibility
  • Small size
  • Metal case, Anti-interference
  • Headphone port output
  • Supports volume adjustment

Specifications

Input:1 SPDIF Optical, 1 Coaxial

  • Output: L-OUT-R; 3.5mm Headphone port
  • Supported Audio formats: MP3, AC3, DTS, WAV, WMA, AAC, ALAC, FLAC, APE, OGG, M4A
  • Signal Noise ratio: 120dB
  • Stereo Isolation: 80dB (1kHz)
  • Channel Unbalance: 0dB
  • Sampling Rate: 32~192KHz
  • Bit Rate: 16~24 Bit
  • Response Frequency: 20Hz~20KHz +/-0.7dB
  • THD: 20Hz~20KHz 0.25-0.065%
  • THD+N: 1kHz 0.15%
  • Analog Output Level: 2.2V
  • Shell Dimension: 81.7 x 78 x 21.2mm
  • Weight: 110g
  • Ports: 1x Optical, 1x earphone jack, 1x L/R, 1x Optical
  • Working Voltage: 5V DC
  • Max power current: 200mA
  • Working temperature: 0-70°C
  • Working Humidity: 10%-80% RH (non-condensing)
  • Storage Temperature: -10-80°C
  • Storage Humidity: 5%%-90% RH (non-condensing)

12 Months

We Offer 12 Months for this product
