4 Way 4k HDMI Switcher With Audio Extractor And Remote

SKU: A3081E
This compact 4-way HDMI switcher features manual & infra-red remote control for switching up to 4 sources to a single display supporting resolutions up to 4K.
$135.45

All Prices Shown are (ex GST)
Bulk Pricing
ea $135.45
2+ $122.73
4+ $113.64
i h
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview

This compact 4-way HDMI switcher features manual & infra-red remote control for switching up to 4 sources to a single display supporting resolutions up to 4k. Ideal for home theatres, showrooms, boardrooms & lecture theatres. Includes power supply & remote control. HDCP compliant. Digital audio signals can be split from the HDMI signal with dedicated TOSLINK output. Audio EDID is selectable to 2.0 or 5.1 modes. ARC function allows the audio from the selected display to be sent to the TOSLINK and 3.5mm jack outputs provided. Automatically switches to last used input on power up. HDMI 2.0. Dimensions: 154W x 70D x 24H mm.

Requires 1 x CR2025 battery for remote (sold separately).

Features

  • Front panel or remote control
  • Uses last used input on power up
  • Simultaneous audio output: Stereo, Toslink and coaxial
  • Supports up to 4k@60Hz progressive scan
  • Handles up to 600MHz/6Gbps per channel (18Gbps max all channels driven)
  • 12 bits per channel (36 bit all channels) deep colour
  • HDCP 2.2 supported
  • Uncompressed LPCM 7.1 audio supported
  • Compressed formats DTS, Dolby Digital (including DTS-HD Master andDolby True HD) supported.
  • Audio Return Channel (ARC) supported

Specifications

Input Digital Signal: 5 Volts p-p (TTL)

  • Output Video: HDMI
  • Output SPDIF Signal: Toslink and Coaxial(RCA)
  • Video Amplifier Bandwidth: 6Gbps/600MHz
  • Video Frequency Range: 50/60Hz
  • Interlaced (50&60Hz): 480i, 576i, 1080i
  • Progressive (50&60HZ): 480p, 576p, 720p, 1080p, 4k
  • Power Supply (Included): 5V DC 2A

Warranty & Returns

12 Months

We Offer 12 Months for this product

Specifications

Products specifications
Warranty Group
Warranty 12 Months
